GARNISSAGES
VRACS METALLIQUES METAL
RANDOM PACKINGS
|
| |
|
|
|
|
|
Dimension
mm
( Od x H x Tck ) |
Bulk Density
( kg/m3 )
refers to SS304 |
Surface
Area ( m2 / m3 ) |
Void Ratio
( % )
|
Packing Factor
( m-1 ) |
Pall 5/8" |
Ø 16 x H
16 x 0.3 |
390
|
366 |
95.2 |
230 |
Pall 1"
|
Ø 25
x H 25 x 0.4 |
311
|
215 |
96.1 |
177 |
Pall 1.5" |
Ø 38
x H 38 x 0.4 |
196
|
133 |
97.5 |
144 |
Pall 2" |
Ø 50
x H 50 x 0.5 |
195 |
105 |
97.6 |
86 |
Pall 3.5" |
Ø 90
x H 90 x 0.7 |
137 |
54 |
98.3 |
56 |
|
|
|
|
|
|
|
|
Thickness
mm
refers
to SS304
|
Bulk Density
( kg/m3 )
refers
to SS304
|
Surface
Area
( m2 / m3 )
|
Void Ratio
( % )
|
Packing Factor
( m-1 )
|
DMTP #15
|
0.25
|
280
|
305
|
96 |
167
|
DMTP #25
|
0.3
|
250
|
220
|
97 |
135
|
DMTP #40
|
0.3
|
180
|
150
|
97 |
79 |
DMTP #50
|
0.4
|
155
|
98
|
98 |
59 |
DMTP #60
|
0.4
|
142
|
85 |
98 |
52 |
| DMTP #70 |
0.5 |
117 |
59 |
98 |
39 |
|
|
|
|
|
|
|
|
|
|
|
Dimension
mm
( Od x H x Tck )
|
Bulk Density
( kg/m3 )
refers
to SS304
|
Surface
Area
( m2 / m3 )
|
Void Ratio
( % )
|
Packing Factor
( m-1 )
|
BMR N°1
|
Ø 25
x H 8 x 0.3
|
240
|
230
|
96 |
125
|
BMR N°2
|
Ø 43
x H 14 x 0.3
|
179
|
144
|
97 |
82
|
BMR N°3
|
Ø 66
x H 22 x 0.4
|
166
|
103
|
97 |
48 |
|
|
|
|
|
|
|
|
Dimension
mm
( Od x H x Tck )
|
Bulk Density
( kg/m3 )
refers
to SS304
|
Surface
Area
( m2 / m3 )
|
Void Ratio
( % )
|
Packing Factor
( m-1 )
|
Raschig 5/8"
|
Ø 16
x H 16 x 0.4
|
520
|
330
|
93 |
558
|
Raschig 1"
|
Ø 25
x H 25 x 0.5
|
388
|
205
|
95 |
450
|
Raschig 1.5"
|
Ø 38
x H 38 x 0.5
|
245
|
128
|
97 |
273 |
Raschig 2"
|
Ø 50
x H 50 x 0.5
|
195
|
101
|
98 |
187 |
Raschig 3.5"
|
Ø 90
x H 90 x 1.0
|
196
|
51 |
98 |
102 |
|
|
|
|
 |
Type
|
Bulk Density ( kg/m3 ) refers
to SS304
|
Surface Area ( m2 / m3 )
|
Void Ratio ( % )
|
Packing Factor ( m-1 )
|
| N° 0.3 |
340 |
315 |
96 |
176 |
| N°
0.5 |
275 |
250 |
97 |
155 |
| N°
0.7 |
185 |
180 |
98 |
120 |
| N°
1 |
165 |
150 |
98 |
82 |
| N°
1.5 |
170 |
120 |
98 |
59 |
| N°
2 |
165 |
100 |
98 |
49 |
| N°
3 |
150 |
80 |
98 |
36 |
|
|
|
|
